ECHOMAP™ UHD2 7" Chartplotters - 72cv With GT20-TM Transducer - 7 inches - 010-02593-01 - Garmin
- Brand: Garmin
- Product Code: 010-02593-01
- Availability: Out Of Stock
- $900.00
- Ex Tax: $900.00
Qty
ECHOMAP™ UHD2 7" Chartplotters - 72cv With GT20-TM Transducer - 7 inches - 010-02593-01 - Garmin
IN THE BOX:
A- With Transducer
- ECHOMAP UHD2 (device varies depending on selection)
- GT20-TM transducer
- Power/data cable
- Tilt mount
- Flush mount
- Hardware
- Documentation
B- Without Transducer
- ECHOMAP UHD2 (device will vary depending on selection)
- Power/data cable
- Tilt mount
- Flush mount
- Hardware
- Documentation
| Built-in Maps | |
| (SOUNDER) TIDE TABLES | yes (see Additional) |
| BLUECHART (COASTAL) | yes (see Additional) |
| LAKEVU (INLAND) | yes (see Additional) |
| GENERAL | |
| DIMENSION | 9.1" x 5.6" x 2.6" (23.2 x 14.3 x 6.7 cm) |
| Display resolution | 800 x 480 pixels |
| Display size | 6.1" x 3.4" (15.5 x 8.7 cm) |
| Display type | WVGA, TN |
| INPUT | Keyed |
| Mounting options | Bail or flush |
| Waterproof protection | IPX7 |
| Weight , | 1.5 lbs (0.7 kg) |
| Chartplotter Features | |
| ACTIVECAPTAIN COMPATIBLE | Yes |
| Sensors | |
| GPS | Yes |
| HAS BUILT-IN RECEIVER | Yes |
| RECEIVER | 5 Hz |
| SUPPORTS WAAS | Yes |
| Maps & Memory | |
| Accepts data cards | 1 microSD™ card; 32 GB maximum size |
| NAVIGATION ROUTES | 100 |
| TRACK POINTS | 50,000 |
| Tracks | 50 saved tracks |
| Waypoints | 5,000 |
| Optional Map Support | |
| (SOUNDER) TOPO | Yes |
| BLUECHART G3 | Yes |
| BLUECHART G3 VISION | Yes |
| GARMIN NAVIONICS VISION+™ | Yes |
| GARMIN NAVIONICS+™ | Yes |
| GARMIN QUICKDRAW CONTOURS | Yes |
| LAKEVÜ G3 | Yes |
| LAKEVÜ G3 ULTRA | Yes |
| STANDARD MAPPING | Yes |
| Connections | |
| 4-PIN TRANSDUCER PORTS | 1 |
| GARMIN WI-FI NETWORK (LOCAL CONNECTION) | Yes |
| Electrical | |
| MAXIMUM CURRENT DRAW AT 12 VDC | 1.5 A |
| MAXIMUM POWER USAGE AT 10 VDC | 18W |
| Power input | 9 to 18 Vdc |
| TYPICAL CURRENT DRAW AT 12 VDC | 1.0 A |
| Sonar Features & Specifications | |
| ClearVü™ | built-in 260/455/800/1000/1200 kHz |
| DISPLAYS SONAR | Yes |
| POWER OUTPUT | 500 W |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) |
| Additional | |
| Additional | BlueChart (coastal): 54cv U.S. BlueChart g3, 55cv U.K./Ireland BlueChart g3, 55cv Australia/New Zealand BlueChart g3, 74cv U.S. BlueChart g3, 75cv UK/Ireland BlueChart g3, 75cv Australia/New Zealand BlueChart g3 // LakeVü: 55cv U.S. LakeVü g3, 55cv Canada LakeVü g3, 73cv U.S. LakeVü g3, 73cv Canada LakeVü g3 // Tide tables: 53cv, 54cv, 55cv, 73cv, 74cv, 75cv |
Tags: Sonar, gps, chartplotter, fishfinder, UHD,
