Apollo Marine Amplifiers - 4 Channel - 150 Watt per Channel - 12 volts - 010-02284-40 - Fusion

Qty

Apollo Marine Amplifiers - 4 Channel - 150 Watt per Channel - 12 volts - 010-02284-40 - Fusion :

What is in the Box:

Fusion Electronics
Fuse rating	4 Channel: 85 A electronic fuse (no replacement necessary)
Operating Voltage	Monoblock/4/6/8 Channel: 10.8 V - 16 V DC
Peak Power (Watts)	4 Channel: 580 watt RMS x 2 @ 14.4 V input - 4 ohm Bridged < 1% THD
Warranty	3 years
GENERAL
Amplifier class	Class-D
CEA-2006 power rating	4 Channel: 150 watt RMS x 4 @ 14.4 V input - 4 ohm < 1% THD
Current consumption (Idle)	4 Channel: < 1.15 A @ 14.4 V input
Current consumption (Max)	4 Channel: 53 A
Current consumption (StandBy)	Monoblock/4/6/8 Channel: < 5 mA @ 14.4 V input // Zone: < 1 mA @ 14.4 V input
Ignition Safety Protected (SAE J1171	Yes
Input impedance	Monoblock/4/6/8 Channel: 22k ohm // Zone: 9k Ohm
Input sensitivity	4/6/8 Channel: 1.3 V RMS
Operating temperature range	0° to 50° C
Physical dimensions with bracket (LxWxH)	Monoblock/4 Channel: 9.25″ x 7.06″ x 2.13″ (235 x 180 x 50 mm)
Physical dimensions without bracket (LxWxH)	Monoblock/4 Channel: 9.25″ x 7.06″ x 1.75″ (235 x 180 x 45 mm)
Protection circuits	Reverse voltage // Input under/over voltage// Over temperature// Output short circuit
Total rated power output - 2 Ohm (Watts)	4 Channel: 1200 watts
Water rating	Monoblock/4/6/8 Channel: IPX2 Zone: IPX7
Weight ,	Monoblock/4 Channel: 4.85 lb (2.2 kg)
