Clarion - CMSP Marine Speakers 6.5" with White and Gray Sport Grille (CMSP-651-SWG) - 010-03047-00 - Garmin
- Brand: Garmin
- Product Code: 010-03047-00
- Availability: In Stock
- $171.17
- Ex Tax: $171.17
Qty
Clarion - CMSP Marine Speakers 6.5" with White and Gray Sport Grille (CMSP-651-SWG) - 010-03047-00:
IN THE BOX:
- Two marine speakers
- Two white grilles
- Two gray metallic grilles
- Twelve 1-1/8" stainless steel screws
CMSP-651-SWG also includes:
- Two 0.250" female crimpable connectors
- Two 0.185" female crimpable connectors
CMSP-651RGB-SWG and CMSP-771RGB-SWG also include:
- Two waterproof 6-pin harnesses
| Fusion Electronics | |
| Tweeter Size | 1" (25 mm) |
| Mounting Dimensions | |
| BOLT HOLE CIRCLE | 6.5": 6.14" (156 mm) 7.7": 6.92" (176 mm) |
| FRONTAL GRILLE PROTRUSION | 6.5": 1.36" (35 mm) 7.7": 1.53" (39 mm) |
| Mounting depth clearance | 6.5": 2.83" (72 mm) 7.7": 3.07" (78 mm) |
| MOUNTING HOLE | 6.5": 5.00"-5.25" (127-133 mm) 7.7" 6.25" (159 mm) |
| Product Specifications | |
| Recommended Amplifier Power (RMS) | 6.5": 30-100 W/Channel 7.7": 40-120 W/Channel |
| GENERAL | |
| COLOUR | White and Metallic Gray |
| Cone material | Injection-molded, mica-filled polypropylene |
| CONTINUOUS POWER HANDLING (RMS) | 6.5": 50W 7.7": 60W |
| Frequency response | 6.5": 55 Hz-20 KHz 7.7": 45 Hz-20 kHz |
| LED lighting | Yes - RGB (Select sport models only) |
| LED load current @14.4 VDC (max) | 140 mA (Select sport models only) |
| LED supply voltage | 10-14.4 VDC |
| Nominal impedance | 4 Ω |
| PHYSICAL DIMENSIONS (DEPTH) | 6.5": 4.19" (106 mm) 7.7": 4.6" (117 mm) |
| PHYSICAL DIMENSIONS (DIAMETER) | 6.5": 6.90" (175 mm) 7.7": 7.7" (196 mm) |
| Sensitivity (1 watt @ 1 metre) | 6.5": 87 dB 7.7": 88 dB |
| SIZES | 6.5"/7.7" |
| SPEAKER TYPE | Coaxial |
| Tweeter type | Silk Dome |
| Warranty | 1 year |
| Connections | |
| speaker connections | Spade Connectors Flying Lead with waterproof connector 18 AWG Wire (Selected sport models only) |
