IPX7 Black Marine Wired Remote with Connectivity to the NMEA 2000® Network, MS-NRX300 - 010-01628-04 - Fusion
- Brand: Fusion Electronics
- Product Code: 010-01628-04
- Availability: Out Of Stock
- $0.00
- Ex Tax: $0.00
Qty
IPX7 Black Marine Wired Remote with Connectivity to the NMEA 2000® Network, MS-NRX300 - 010-01628-04:
IN THE BOX:
- Fusion® NRX300 black wired remote
- Mounting gasket
- Four 8-gauge, self-tapping screws
- Two screw covers
- 6 metres (20 ft) drop cable for the NMEA 2000 network
- T-connector for the NMEA 2000 network
- Dust cover
- Documentation
| Remote features | |
| DISPLAY SIZE | 2.6″ optically bonded monochrome LCD |
| SUPPORTED NMEA 2000 PGN DATA | 127250 - Heading sensor reference (true, magnetic) 128259 - Water speed reference (paddle wheel, pitot tube, doppler log, correlation log, electromagnetic log) 128267 - Water depth (offset add or subtract) 129025 - Position (latitude and longitude) 129026 - Course Over Ground (COG) and Speed Over Ground (SOG) [COG reference true, magnetic] 129029 - Global Navigation Satellite System (GNSS) position data 129284 - Navigation data (ETA) 130306 - Wind data reference (apparent wind relative to the vessel centerline) 130310 - Water temperature and air pressure 130311 - Water temperature and air pressure 130312 - Temperature and temperature source (sea temperature) |
| Security information | |
| SECURITY UPDATES UNTIL AT LEAST (YYYY-MM-DD) | 2026-01-29 |
| GENERAL | |
| Current (max.) | 110 mA at 12 VDC |
| Operating temperature range | 0° to 50° C (32° to 122° F) |
| Physical dimensions | 70 x 110 x 50 mm (2.76″ x 4.33″ x 1.97″) |
| Power input | 10.8-16 VDC |
| Warranty | 3 years |
| Water rating | IPX7 |
| Sensors | |
| NMEA 2000 COMPATIBLE | One USB 2.0 port |
