Piranha P12 MK11 - Suitable for boats up to 20m, 65ft - 12/24V - 7200 Lumen - P12-SM-B134X - Bluefin Led
- Brand: Bluefin Led
- Product Code: P12-SM-B134X
- Availability: Out Of Stock
- $673.87 $792.79
- Ex Tax: $673.87
Available Options
Piranha P12 MK11:
Suitable for boats up to 20m, 65ft
Overview:
Surface Mounted LED Underwater Boat Light.
> The P12 produces a class-leading 7,200 Fixture Lumens, this high-quality AB2 Bronze fixture offers amazing value for money and outperforms comparably priced products such as Ocean LED`s Sport s3116s, Lumishore SMX52 & Lumitec Seablaze X.
> The Piranha P12 is available as a single color fixture in either white or blue or as a dual-color fixture white/blue.
> Lights are controlled via a simple on/off toggle switch off then on to select color or strobe (flashing) mode.
> Ultra-compact low profile design is perfect for all types of boats, suitable for transom and side mounting on all hull types.
> Incredibly simple to install just one small cable entry hole and 3 mounting screws. Reverse polarity protection with in-built driver technology and active thermal rollback.
> Suitable for use in and out of water use.
> RINA Type Approved
SPECIFICATION:
> Suitable transom or side hull mounting
> Surface mount, requires 13mm cable entry hole
> Recommended for boats up to 20m/65ft
> Max Lamp Lumens 9,100 / Fixture Lumens 7,200
> Typical LED life expectancy 50,000 + hours
> Voltage 12V 4.6 Amps, 24V 2.35 Amps
> Over voltage,current,reverse polarity,active thermal protection
> Fixture profile 17.6mm
> Fixture diameter 110mm
> Lens: optical grade high impact polymer,60 degree beam angle
> IP69K Rated
> 2 years warranty
> Swimming pool option available
> Made in England
What is in the box:
> In-line fuse holder
> rated fuse
> Gel connector
> Inline Crimps
> Heat
> shrink
> Fixing Screws
> Template
> installation instructions
| Accessories options | |
| 220/110v Power Supply | Power supply 24v for up to 5 lights |
| I.Y.S Lighting Control | Control via MFD screen or mobile device |
| Junction Box | 4 Way IP68 Wiring Junction Box |
| Specifications | |
| Attatched cable length | 1.8 meter Over-moulded |
| Available Colours | Diamond White 6500k// Cobalt Blue // Sapphire Blue // Dual Colour White/Blue |
| Beam Angle | 60 Degree |
| Driver Type | Integral |
| Fixture Diameter | 110mm |
| Fixture Lumens | 6800 |
| Fixture Material | AB2 Bronze (standard) or Aluminium |
| Fixture Profile | 17.6mm |
| Hole cut out size | 15mm |
| Included in box | In-line fuse holder & rated fuse, Gel connector, Inline Crimps, Heat shrink, Fixing Screws, Template, and installation instructions |
| Lens Type | 3mm Optical grade high impact polymer, Guard X Coating |
| Max Wattage | 55 watts |
| Maximum Lamp Lumens | 9000 |
| Mounting Type | Surface |
| Power Draw | 4.6 amps @ 12v / 2.35 amps @ 24v |
| Protection | Over / Under Voltage, Over Current, Reverse Polarity protection, Active thermal protection. Hydro block technology |
| Spacing | 1.2 - 2mtr |
| Suitable Use | Above & below the water-line |
| Total weight | 500 gm |
| Type Approval | RINA IEC 60529 |
| Typical Life Expectancy | 50,000 Hours |
| Voltage range: | 12v/24v Multi-voltage |
| Warranty | 2 Year |
