VHF Marine Handheld Transceiver M85E - M85E-27:

Marine and PMR Hybrid for Professional Use

Compact and Lightweight

The IC-M85E is the most compact (W×H×D: 56 × 92 × 29 mm) and lightweight (weight: 246 g (with BP-290, FA-SC58V, and MBB-3)) commercial grade marine and land mobile hybrid radio in the world

Covering 136–174 MHz PMR Frequency

In addition to VHF marine channels, the IC-M85E covers 136–174 MHz PMR channels. Up to 100 programmable channels are available for PMR use. Each channel is programmable with CTCSS and DTCS tones.

700 mW Powerful Audio

Despite its compact body, the IC-M85E delivers 700 mW of loud audio. Clear communication is vital in noisy environments.

Private Conversation

The radio has a built-in Voice Scrambler and provides private communication between stations (32-code, compatible with UT-112 voice scrambler unit).

Automated Emergency Alarm

The IC-M85E has three emergency-related functions: the MOB Alarm, Man Down, and Lone Worker function. If one of these functions is activated, the radio automatically makes an emergency alarm.

Instant Operation with Multi-Function Button

Channel group changing (marine ⇔ PMR) or the scrambler function ON/OFF can be assigned in the multi-function button on the top panel*. The Key lock function can be activated by holding the button.

IP67 and MIL-STD Rugged Construction

The IC-M85E is built and durable to endure 1 m submersion for 30 minutes and dust-tight protection. The radio also passes MIL-STD-810 specifications.

And More

●AquaQuake prevents audio degradation from a water-logged speaker

●Internal VOX capability for hands-free operation

●14 hours of long battery life (TX: RX: Standby=5:5:90.)

●5 W output power

●The self-check function checks internal temperature, and connected battery voltage (over voltage detection)

●Monitor function

●Priority scan function

●Dual/Tri-watch function for monitoring CH16 and/or call channel

●Favorite channel function for quick access to often used channels

Applicable U.S. Military Specifications

Standard

MIL 810 G

	Method	Procedure
Low Pressure	500.5	I, II
High Temperature	501.5	I, II
Low Temperature	502.5	I, II
Temperature Shock	503.5	I-C
Solar Radiation	505.5	I
Rain Blowing/Drip	506.5	I, III
Humidity	507.5	II
Salt Fog	509.5	–
Dust Blowing	510.5	I

Immersion	512.5	I
Vibration	514.6	I
Shock	516.6	I, IV

Applicable IP Rating

Ingress Protection Standard
Water	IP67 (Dust-tight and waterproof protection)

Supplied Accessories

BP-290 battery pack
BC-227 rapid charger
BC-123S* AC adapter
FA-SC58V antenna
MBB-3 belt clip
Hand strap

SE for Europe plug. SUK for UK plug. SV for Australia plug.

Optional Accessories

RECEIVER
Adjacent channel selectivity	70 dB
Audio output power, External SP	700 mW typical (at 10% distortion with 8 Ω load at 1 kHz)
Audio output power, Internal SP	700 mW typical (at 10% distortion with 12 Ω load at 1 kHz)
Hum and noise	40 dB
Intermodulation	68 dB
Sensitivity (at 20 dB SINAD)	-4 dBμ emf typical
Spurious response	70 dB
TRANSMITTER
Audio harmonic distortion	10% (at 60% deviation)
Frequency stability	±1.5 kHz
Max. frequency deviation	±5.0 kHz
Modulation limiting	60-100% of maximum deviation
Output power (at 7.2 V DC)	5/3/1 W
Residual modulation	40 dB
Spurious emissions	0.25 μW (≤2 GHz),1.0 μW (>2 GHz)
GENERAL
Antenna impedance	50 Ω
Channel spacing	25 kHz
Current drain (approximate), Rx Max. audio	0.45 A
Current drain (approximate), Tx (at 5 W)	1.5 A
Dimensions (W×H×D) (Projections not included)	56 × 92 × 29 mm (With BP-290)
Frequency coverage RX	156.000–163.425 MHz
Frequency coverage TX	156.000–161.450 MHz
Operating temperature range	Marine channels: -15 °C to +55 °C
Power supply requirements	7.2 V DC nominal
Type of emissions	16K0G3E
Usable channel groups, Number of channels	INT, USA* channels (* Varies according to version)
Weight (approximately)	246 g (with BP-290, FA-SC58V and MBB-3)
