GPSMAP 1623xsv , SideVü, ClearVü and Traditional CHIRP Sonar with Worldwide Basemap, 010-02919-02 - Garmin
- Brand: Garmin
- Product Code: 010-02919-02
- Availability: In Stock
- $5,825.15
- Ex Tax: $5,825.15
GPSMAP 1623xsv, SideVü, ClearVü and Traditional CHIRP Sonar with Worldwide Basemap, 010-02919-02 - Garmin
IN THE BOX:
| Built-in Maps | |
| TIDE TABLES | Yes |
| GENERAL | |
| DIMENSION | 15.1” x 10.3” x 3.0” (38.4 x 26.2 x 7.6 cm) |
| Display resolution | 1920 x 1080 pixels |
| Display size | 13.6" x 7.7"; 15.6" diagonal (34.5 cm x 19.5 cm; 39.7 cm diagonal) |
| Display type | FHD, IPS |
| INPUT | Touchscreen |
| Mounting options | Bail, flush or flat (Garmin does not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.) |
| Touchscreen | Yes |
| Water rating | IPX7 |
| WEIGHT | 9.7 lbs (4.4 kg) |
| Chartplotter Features | |
| ACTIVECAPTAIN® COMPATIBLE | Yes |
| AIS | Yes |
| DSC | Yes |
| GCV BLACK BOX SONAR SUPPORT | Yes |
| GSD BLACK BOX SONAR SUPPORT | Yes |
| ONEHELM SUPPORT | Yes |
| Sailing Features | Yes |
| SMART MODE COMPATIBLE | Yes |
| SPOKEN AUDIO ALERTS | Yes |
| SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS | Yes |
| Wireless remote compatible | Yes |
| Sensors | |
| Galileo | Yes |
| GLONASS | Yes |
| GPS | Yes |
| HAS BUILT-IN RECEIVER | Yes |
| NMEA 0183 COMPATIBLE | Yes |
| NMEA 2000 COMPATIBLE | Yes |
| RECEIVER | 10 Hz |
| SUPPORTS WAAS | Yes |
| Maps & Memory | |
| NAVIGATION ROUTES | 100 |
| TRACK POINTS | 50,000 |
| Tracks | 50 saved tracks |
| Waypoints | 5000 |
| Optional Map Support | |
| GARMIN NAVIONICS VISION+™ | Yes |
| GARMIN NAVIONICS+™ | Yes |
| GARMIN QUICKDRAW CONTOURS | Yes |
| RASTER CHART SUPPORT | Yes |
| STANDARD MAPPING | Yes |
| TOPO 100K | Yes |
| Connections | |
| Video output ports | 1 HDMI |
| Connections | |
| 12-PIN TRANSDUCER PORTS | 1 |
| ANT+ (CONNECTIVITY) | Yes |
| GARMIN MARINE NETWORK PORTS | 2 |
| GARMIN WI-FI NETWORK (LOCAL CONNECTION) | Yes |
| J1939 PORTS | 1 |
| USB PORTS | Yes |
| Electrical | |
| MAXIMUM CURRENT DRAW AT 12 VDC | 6.07 A |
| MAXIMUM POWER USAGE AT 10 VDC | 74.75W |
| Power input | 10 to 32 Vdc |
| TYPICAL CURRENT DRAW AT 12 VDC | 3.61 A |
| Sonar Features & Specifications | |
| ClearVü™ | built-in 260/455/800/1000/1200 kHz |
| DISPLAYS SONAR | Yes |
| LIVESCOPE | Yes |
| PANOPTIX™ SONAR | Yes |
| POWER OUTPUT | 1 kW |
| SideVü™ | built-in 260/455/800/1000/1200 kHz |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | built-in (single channel CHIRP, 50/70/83/200 kHz, L, M, H CHIRP) |
Tags: Chartplotter, Fishfinder, Sonar, Control, GLONASS, Transducer,
