STRIKER Vivid 5cv With GT20-TM Transducer - 010-02551-01 - Garmin
- Brand: Garmin
- Product Code: 010-02551-01
- Availability: Out Of Stock
- $405.41
- Ex Tax: $405.41
STRIKER Vivid 5cv With GT20-TM Transducer - 010-02551-01 - Garmin:
IN THE BOX:
- STRIKER Vivid 5cv
- GT20-TM transducer
- Power/data cable
- Tilt/swivel mount
- Hardware
- Garmin bumper sticker
- Documentation
| GENERAL | |
| DIMENSION | 7.4’’ x 4.5’’ x 2.1’’ (18.8 x 11.6 x 5.4 cm) |
| Display resolution | 800 x 480 pixels |
| Display size | 2.6" x 4.3" (6.5 x 10.8 cm); 5.0" diag (12.8 cm) |
| Display type | WVGA colour |
| INPUT | Keyed |
| Mounting options | flush, tilt/swivel |
| Waterproof protection | IPX7 |
| WEIGHT | 1.0 lb (0.5 kg) |
| Sensors | |
| GPS | Yes |
| HAS BUILT-IN RECEIVER | Yes |
| SUPPORTS WAAS | Yes |
| Maps & Memory | |
| NAVIGATION ROUTES | 100 |
| TRACK POINTS | 50,000 |
| Tracks | 50 |
| Waypoints/favourites/locations | 5000 |
| Optional Map Support | |
| GARMIN QUICKDRAW CONTOURS | Yes |
| Connections | |
| 4-PIN TRANSDUCER PORTS | 1 |
| Electrical | |
| MAX CURRENT DRAW | 1.5 A |
| POWER CONSUMPTION | 4.8 |
| Power input | 12 to 20 Vdc |
| TRANSMIT POWER | 500 W (RMS) |
| TYPICAL CURRENT DRAW | 0.40 A |
| Sonar Features & Specifications | |
| Bottom lock (shows return from the bottom up ) | Yes |
| ClearVü™ | Yes |
| DISPLAYS SONAR | Yes |
| FREQUENCY | Traditional: 50/77/200 kHz CHIRP (mid and high) ClearVü: 260/455/800 kHz |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | Built-in |
| WATER TEMPERATURE LOG | Yes |
| Fishfinder Features | |
| A-scope | Yes |
| Adjustable depth line (measures depth of underwater objects) | Yes |
| AutoGain Technology (minimizes clutter, maximizes targets) | Yes |
| DEPTH RANGE SHADING | Yes |
| Fish Symbol ID (helps identify fish targets) | Yes |
| Split-screen zoom | Yes |
| Water temperature sensor included | Yes |
| Additional | |
| Additional | One 4-pin transducer port // Quickdraw Contours // Integrated GPS // Mark Waypoints // Course over Ground (COG) // Current draw @ 12V: 0.40A |
Tags: Fishfinder, GPS, Sonar,
