DC Diaphragm Pump - 35 Series - 7.0 LPM - 80 PSI 12V/24V - SFDP1-018-080-35X - Seaflo
- Brand: Seaflo
- Product Code: SFDP1-018-080-35X
- Availability: In Stock
- $108.11
- Ex Tax: $108.11
DC Diaphragm Pump - 35 Series - 7.0 LPM - 80 PSI 12V/24V - SFDP1-018-080-35X - Seaflo:
The 35-Series is our continuous-duty on-demand positive displacement pump.
Quick-attach fittings allow for easy installation or replacement.
It provides reliable performance in moderate water flow, high-pressure applications.
This 3-chamber diaphragm pump provides up to 1.8 gallons per minute and is capable of self-priming up to 6 vertical feet, and can run dry without damage.
Miniature multi-outlet water pressure pump serves 1 or 2 3/8” (10 mm) outlets at any one time.
This automatic demand water system pump has a built-in pressure switch, which automatically starts and stops when the fixture is opened and closed.
They are easy to install, service and winterize.
| ||||||||||||||||
| ||||||||||
PERFORMANCE: |
| PRESSURE | FLOW | CURRENT | ||
| PSI | BAR | GPM | LPM | APMS |
| 0 | 0 | 1.55 | 5.85 | 3.57 |
| 10 | 0.69 | 1.47 | 5.55 | 4.16 |
| 20 | 1.38 | 1.40 | 5.30 | 4.84 |
| 30 | 2.07 | 1.33 | 5.05 | 5.50 |
| 40 | 2.76 | 1.27 | 4.80 | 6.25 |
| 50 | 3.45 | 1.22 | 4.60 | 6.71 |
| 60 | 4.14 | 1.15 | 4.35 | 7.23 |
| 70 | 4.83 | 1.07 | 4.05 | 7.73 |
| 80 | 5.52 | 1.06 | 4.00 | 8.20 |
| Model | Voltage | Open Flow (GPM/LPM) | Control Type | Max Draw | Shut-off Pressure (PSI/BAR) | Valves | Diaphragm | Ports | Wire Connections |
| SFDP1-018-080-35 | 12V | 1.8 / 7.0 | Switch | 9.0 | 80 / 5.5 | EPDM | Santoprene | QUICK ATTACH | 2-Pin/Leads |
| SFDP2-018-080-35 | 24V | 1.8 / 7.0 | Switch | 4.5 | 80 / 5.5 | EPDM | Santoprene | QUICK ATTACH | 2-Pin/Leads |
Tags: Pump, Diaphragm, Maintenance, Perfect,
