Diaphragm Pump 21 Series - 4.3 LPM - 12V - SFDP1-012-035-21:
Features & Benefits:
Compact design
Heavy-duty demand switch
Can run dry
Quiet operation
Industry standard mount pattern
Typical Applications:
Marine/RV
Water Treatment/Ro
Beverage/Food Service
Distillation Equipment
Agricultural Spraying
General Industrial
Automotive
PUMP:
Type
2 Chamber positive displacement diaphragm
pump, self priming, capable of being run dry
Max Recommended Temperature
110°F (43°C) Max.
Priming Capabilities
4 feet (1.2 m) suction lift
Max Pressure
40PSI (2.8bar)
Inlet/Outlet Ports
3/8" hose barb
Weight
1.25 lbs (0.57 kg)
MOTOR:
Duty Cycle
Intermittent
Leads
18 AWG, 13.78" long with
2-Pin connector/Leads
Voltage
12v/24v
Model
| Voltage
| GPM/LPM
| Switch
| Amps
| PSI/BAR
| Valves
| Diaphragm
| Ports
| Wire Connections
|
SFDP1-012-035-21
| 12V
| 1.2/4.3
| Demand
| 4.0 MAX
| 35/2.4
| EPDM
| Santoprene
| | 2-Pin/Leads
|
