Diaphragm Pump - 2.8 Bar - 6LPM - DP1-016-040-23 - Seaflo

Diaphragm Pump - 6LPM - DP1-016-040-23:

Features:

- Maximum torque and operating efficiency

- Higher operating pressure and/or lower amperage than competitive pumps Long life, no leaks

- Low noise; acid, alkali and corrosion resistant

- Run dry with no problem

Functions:

Motor Voltage: 12/24V DC，220V AC

Max Flow rate: 6.0lpm - (1.6gpm)

Max Pressure: 40psi(2.8bar), can be adjusted from 10psi(0.6bar) to 40psi(2.8bar) as required.

Inlet/Outlet fitting: 12.5mm pyramid  hose barb,1/4 NPT male thread fitting, etc for your choice.

Protection: pressure switch protection, pressure-off protection or circumfluence switch protection.

Duty Cycle: Intermittent (under different pressure the continuous working time will also be different).
