The best choices when you are looking for high performance, heavy duty pumps designed to meet the tough demands of commercial and recreational duty.
Both pumps may be automatically controlled with either an automatic switch AS888 or an electronic float switch.
Order No.
| Description
| Capacity 1.0 m head (13.6 V/27 V)
| Capacity straight (13.6 V / 27 V)
| Amperage
| Fuze Size
| Connection
|
32-2200-01 | L 2200, 12 V | 120L/min - 1900 GPH | 130 L/min - 2060 GPH | 7.5 A | 12 A | 1.1/8" and 1.1/4" |
32-2200-02 | L 2200, 24 V | 120L/min - 1900 GPH
| 130 L/min - 2060 GPH
| 4.5 A | 6 A | 1.1/8" and 1.1/4"
|
Technical Features:
• Heavy duty, 12-pole double ball bearing motor
• Liquid cooled for extended motor life
• Quality engineered mechanical/lip seal
• ISO 8849 Marine and CE standards
• Easily interchangeable with most similar bilge pumps
Design features:
* Pump body: Thermoplastic
* Shaft seal: L2200 - Mechanical seal
* Shaft: Stainless steel (SS2343)
* Voltage: 12 V or 24 V DC
* Hose sizes: 1.1/8" or 1.1/4"
* Max Dia: 108mm
* Max Height: 177mm
* Weight: 2.25kg
Order No:
32-2200-01 L2200 12 V 130 L/min
32-2200-02 L2200 24 V 130 L/min
